Wall Putty Ceramic Tile Adhesive Machine Dry Mortar Machines Ceramic Tile Adhesive Making Machine


Wall Putty Ceramic Tile Adhesive Machine Dry Mortar Machines Ceramic Tile Adhesive Making Machine for Introduction

Wall Putty Ceramic Tile Adhesive Machine Dry Mortar Machines Ceramic Tile Adhesive Making Machine

Dry mortar mixers can meet the production needs of dry mortars, dry materials, and dry adhesives with varying performance requirements, such as putty powder, dry paint, masonry mortar, plaster mortar, mortar for insulation systems, decorative mortar, and other dry mortars. They offer numerous advantages, including small footprint, low investment, rapid results, and simple operation.

Wall Putty Ceramic Tile Adhesive Machine Dry Mortar Machines Ceramic Tile Adhesive Making Machine for Description

Wall Putty Ceramic Tile Adhesive Machine Dry Mortar Machines Ceramic Tile Adhesive Making Machine

To reduce the cost of replacing vulnerable parts, the paddle blades can be made into two pieces. A removable small blade is placed on the blade base, allowing for quick and easy replacement of worn blades. The discharge method generally uses a pneumatic (or manual) flap valve. The arc valve fits tightly into the barrel, flush with the inner wall, eliminating material accumulation and dead corners. The standard model is available in either a large or small opening. The large opening opens to the edge of the barrel, ensuring clean and quick discharge with minimal residue.

Wall Putty Ceramic Tile Adhesive Machine Dry Mortar Machines Ceramic Tile Adhesive Making Machine for Specification

Wall Putty Ceramic Tile Adhesive Machine Dry Mortar Machines Ceramic Tile Adhesive Making Machine

No. Equipment Specification Qty Power

(KW)

Total Power(kw) Place of Origin


Raw material storage ,drying and screen system

1 Wet sand hopper 2.2*2.5m 1 set HCCM – China
2 Drying system 1 set HCCM – China
3 Feeding system Frequency Control 1 set 3kw 3kw HCCM – China
4 Belt conveyor 500*8000

10# steel

1 set 5.5kw 5.5kw HCCM – China






5







Dryer

Model: 6215

Body: Φ2.2*4.5 Reducer: ZQ350 Base: 2.3m (L) × 2.1m (W)

Outlet bin φ1.65m







1 set









7.5kw









7.5kw







HCCM – China

6 Dust collector system 4.5*1260 1 set 11kw 11kw HCCM – China
7 Vibrating screening Model:1030 1 set 1.5kw 1.5kw HCCM – China
8 Dry sand belt 500*6000

10# steel

1 set 3kw 3kw HCCM – China
9 Burner and Hot stove 1 set HCCM – China
